English 英文站50KG
Curb weight Ultra-Lightweight design100+KM
Effective cruising range Fast charging within 3 hours250N.M
Maximum Torque Climbing angle over 45 degrees
Excellent performance combined with exciting appearance
The light bee combined the both high torque from dirt bike and lightweight and agility from downhill bicycle.Under the dynamic appearance , it hides a wild and enthusiastic heart.
Learn MoreSelf-developed Intersect TR Rear Suspension System
After thousands of times on cross-country tracks and urban road tests, we have created an amazing multi-link rear suspension system for the light bee. The appearance is integrated with the overall vehicle structure, and the shock absorption performance is also adjusted according to the usage characteristics of electric bikes, so that the tires can maintain the best grip continuously.
Learn More1260mm
Short wheelbase design Easy to ride270mm
Minimum Ground Clearance Easy to recover when stuck203mm
Large size disc brake Strong braking performanceExcellent sport performance
In the sports mode, the strong power output up to 5KW and the instantaneous erupted on-wheel torque with 250N.m, makes you easy to handle skills like jumping and wheelie etc.. Additionally, the 19-inch professional off-road wheel set is excellent in the abilities of passage and never gets stuck. All of these contribute to the better sport performance.
High Performance Motor
Maximum rotate speed 5400 rpm Protection level IP55FOC Sine Wave Controller
Multi-Curve Compound Algorithms Full encapsulation structureHigh-power battery pack
High rate 18650 cell Safe and reliableWell matched EIC system
The EIC system is self-developed by SURRON. After five test riding trips in Sichuan and Tibet Province, as well as the continuous feedback from the top riders all around the world, the EIC system is set to adapt more challenging and harsh riding scenarios.
Light Bee your move in all terrain
Whether in the mountain trails, the snowy forest, the professional competition ground or the street alleys, the Light bee can adapt to all road conditions and also show its unique attitude and the characteristic of charging at anytime and anywhere.
Whether in the mountain trails, the snowy forest, the professional competition ground or the street alleys, you can ride your Light bee anywhere, anytime.
Whether in the mountain trails, the snowy forest, the professional competition ground or the street alleys, you can ride your Light bee anywhere, anytime.
Easy to handle the classic skills
Wheelie, drifting, tyre burn-out and jumping, all these skills can be easy to handle after riding on the Light Bee. It can be used for the first learning by newcomers, competition among friends, parent-child interaction and professional training. Everyone can enjoy the fun of riding Light Bee. riding Light Bee.
Order
Dimension: 1860mm×780mm×1050mm
Ground clearance: 270mm
Wheel base: 1255mm
Seat height: 830mm
Dry/Curb weight: 45kg/56kg
Carrying capacity: 100kg
Front fork travel: 200mm
Rear shock/wheel travel: 87/210mm
Power system: Mid-drive BLDC motor + FOC sine wave controller
Maximum power: 5000W
Maximum torque: 250N.m
Top speed: 75km/h
Range: 100km（@20km/h）
Battery Type: 60V/32Ah lithium-ion removable battery pack
Charge time: 3-4h
Frame design: aluminum forged frame
Front tire: 70/100-19
Rear tire: 70/100-19
Riding mode: SPORTS + ECO mode
Assistance functions: Regen(on SPORTS mode)
High Performance Brake System
Opposed Four Piston Hydraulic Brake System，Reliable Highbrake performance，Metallica Brake Pad represent High brake
performance and long durability，203mm brake Disc can achieve
more immediate and safer braking action
7.8KG Ultra-Lightweight Frame
Aviation standard aluminum alloy forged by 6000 tons pressures，one of the top G3 curve design in the industry，fully automatic welding process to ensure the consistency in production
All-day GPS monitoring
built-in high precision GPS.sign up at sur-ron official appand connect your bike to your phone. Tracking your bike
location and review your riding route at anytime and anywhere
Order
SURRONxKKE
Complete new designed suspension system
Adjustable rebound
spring preload adjustable
200mm effective travel, can easily stand big jump,
and overall smooth suspension feel
Designed with triple rate coil spring installed,
gives you a much better fork stability
working perfectly on both trail and track condi-
tions or daily riding terrain
RST Light weight Conventional
Anodized Black Fork
Special design for Light Bee X version RA compressiondamping preload damping reduced 4-6 kfg Rebound Adjust
according to the terrain and riding style, Oil injection
port available, easy to maintenance Anodized black
surface treatment adding PTFE coating, made the fork
travelling smoother, more heat resistance, more waterproof
and more corrosion resistance.200mm fork suspension travel
DNM High Performance
Up-side-down Fork
Rebound damping special design for Light Bee Xversion, adjustable spring preload Customized CNC
clip added to the inner tube, increase the strength
and the stiffness of the fork 203mm fork travel,
extremely good at shock absorb and filter
18650
Using 18650 Lithium battery cell, equipped with safe and efficient BMS, the battery pack can produce sufficient and stable power. 4 temperature sensor and 485 communication protocol ensure the high-power load capacity and service life of the battery pack. The whole battery pack weighs only 11KG. Less than 10 seconds quick assembly or disassembly, easy to charge anytime, anywhere.Excellent FOC Intelligent sine wave controller
SURRON independently design and develop, multi-curve compound algorithm program, real-time monitoring of throttle turning angle, speed, motor torque and current intensity, and will continuously analyze and learn your daily riding data to make it compliance with your riding habits.High Efficiency center placed Motor
High Performance Brushless Permanent Magnet Synchronous Motor, SURRON design and developed dedicated to Light Bee,a powerful heart with efficient electronic braking function. IP55 Protection level,
High-grade permanent magnet material withstands high temperatures up to 180 ° C with peak torque of 32 N.m
